Front and rear hydraulicshock absorption
Shock-absorbing effect is good, greatly enhance riding comfort
Vehicle NameTK10
Parameters
- Configuration Code(24th edition)
- Loading Capacity2
- Size(Length * Width * Height) 1770*700*1120mm
- Max Speed45km/h
- Input VoltsAC220V (adjustable 110V)
- Distance between axles1300mm
- Distance between wheels/ mm
- Minimum Ground Clearance>135 mm
- Minimum Turning Radius≤1.97 m
- Brake Distance（20km/h）≤4 m
- Slope-Climbing≤12 °
- Battery60V20AH (LEAD-ACID）
- Battery Weight35KG
- Max load150kg
- Weight(excluding battery)57kg
- Mileage70-90km
Electronic control parameters
- ContronlDC controller, 60V12T30A
- MotorDC permanent magnet wheel motor, 60V27H800W
- Charger60V3A, filled with 6-8 hours
- Lights & SignalsFront headlights/turn signals/tail lights/horn
- AcousticsNothing
- SwitchesElectric door lock/light/three speed
- Panel boardLCD instrument, phase line instrument
- Other functionsNothing
- Windshield wiperNothing
Body and chassis
- SeatsTwo person economy seat
- Body & FrameTubular frame
- BodyNothing
- Body/Sealed DoorAutomotive grade pedal leather
- Windshield & Side mirrorsEquipped with instrument windshield and driver's dual rearview mirrors
- Turning SystemTurn the steering wheel
- Front axle & SuspensionHydraulic shock absorber with a diameter of 27
- Rear axle & SuspensionHydraulic shock absorber with a diameter of 32 pipes
- Brake systemFront disc and rear hub
- TyreFront and rear 3.0-10 vacuum tires/front wheel hub 2.15-10 aluminum wheels
- Safety BarNothing
Loading
- 20 feet (for small-sized models)Half scattered SKD45 units. 65 sets of fully dispersed CKD are expected to be verified.
- 40 cabinetsSemi scattered SKD105 units. Complete CKD 150 sets.
Others
- OthersStandard raincoat
- Color profileMoon White, Transparent Red Maroon tm, Bright Black
