Front and rear hydraulicshock absorption
Shock-absorbing effect is good, greatly enhance riding comfort
Vehicle NameERVS3
Parameters
- Configuration Code(24th edition)
- Loading Capacity1+2
- Size(Length * Width * Height) 2230*835*1700mm
- Max Speed32km/h
- Input VoltsAC220V (adjustable 110V)
- Distance between axles1450mm
- Distance between wheels700 mm
- Minimum Ground Clearance>95mm
- Minimum Turning Radius≤2.4m
- Brake Distance(30km/h)≤7.5m
- Slope-Climbing≤6 °
- Battery48V32AH (LEAD-ACID） 51.2V32AH(Lion）
- Battery Weight40KG 18.5KG
- Max load
- Weight(excluding battery)141kg
- MileageLead acid: 49.1km (single person 75kg, 3rd gear) 37km (full load 225kg, 3rd gear) Lithium battery: 40.1km (single person 75kg, 3rd gear) 39.3km (full load 225kg, 3rd gear)
Electronic control parameters
- ContronlSquare wave controller, 48V12T28A
- MotorMid mounted differential motor, 48V30H500W
- ChargerLead acid: 48V4A, fully charged 6-8 hours/Lithium: 57.6V8A, fully charged 4-5 hours
- Lights & SignalsFront headlights/turn signals/tail lights/horn
- AcousticsUSB charging
- SwitchesElectric door lock/light (dual flashing)/three speed/reverse
- Panel boardLED instrument, 1-wire communication&485 instrument
- Other functionsForward reverse/anti slip slope/speed limit/soft and hard start, USB charging
- Windshield wiperHave
Body and chassis
- SeatsFront single seat, rear one person comfortable seat or two person economy seat
- Body & FrameNon load bearing frame
- BodyPlastic roof
- Body/Sealed DoorPlastic foot pedal
- Windshield & Side mirrorsTempered glass, driver's dual rearview mirrors with turn signal function
- Turning SystemTurn the steering wheel
- Front axle & SuspensionΦ 31 hydraulic shock absorber
- Rear axle & SuspensionRear axle structure with Φ 32 pipe hydraulic rear shock absorber
- Brake systemFront and rear disc brakes
- TyreFront tire 16 * 3.0, rear tire 3.0-10 vacuum tire/front wheel hub 1.5-12, rear wheel hub 2.15-10 aluminum wheel
- Safety BarNothing
Loading
- 20 feet (for small-sized models)Semi scattered SKD14 steel edged boxes (wooden boxes). 48 sets of fully dispersed CKD are expected to be verified.
- 40 cabinetsHalf scattered SKD42 steel edged boxes (wooden boxes). Complete CKD110 sets.
Others
- OthersEquipped with rain curtains
- Color profileTransparent Red Maroon tm, Honda Grey, Moon White, Fruit Green, Strawberry Bear Pink, Ice Blue
